WALL PLUG

A101
SIZE
4 x 20 8 x 40
5 x 25 10 x 50
6 x 30 12 x 60
7 x 35 14 x 70






WALL PLUG

A102
SIZE
5 x 25 6 x 30
8 x 40 10 x 50






FRAME PLUG & SCREW ASSEMBLY TOGETHER



A103
SIZE
5 x 30
8 x 100
5 x 40
8 x 120
5 x 50
10 x 80
6 x 40
10 x 100
6 x 60
10 x 120
6 x 80
10 x 140
8 x 60
10 x 160
8 x 80




NAIL & PLUG ASSEMBLY TOGETHER



A104
SIZE
6 x 35
6 x 40
6 x 50
6 x 55
6 x 60
6 x 70
6 x 80
8 x 50
8 x 60
8 x 80
8 x 100
8 x 120
8 x 140
8 x 160




NYLON NAIL ANCHOR



A105
SIZE
3/16" x 3/4"
3/16" x 1"
3/16" x 1-1/2"
1/4" x 3/4"
1/4" x 1"
1/4" x 1-1/2"
1/4" x 2"
1/4" x 3"




NYLON NAIL ANCHOR

A106
SIZE
3/16" x 3/4"
3/16" x 1"
3/16" x 1-1/2"
1/4" x 3/4"
1/4" x 1"
1/4" x 1-1/2"
1/4" x 2"
1/4" x 3"




NYLON NAIL ANCHOR

A107
SIZE
3/16" x 3/4"
3/16" x 1"
3/16" x 1-1/2"
1/4" x 3/4"
1/4" x 1"
1/4" x 1-1/2"
1/4" x 2"
1/4" x 3"




CONICAL PLASTIC ANCHOR

A108
SIZE
5 x 19
6 x 22
8 x 26
10 x 34






PLASTIC ( TOGGLE ) ANCHORS


A109
SIZE
10 x 40
10 x 47




PLASTIC ( TOGGLE ) ANCHORS


A110
SIZE
MM
INCH
3 - 5
1/8" ~ 3/16"
9 - 13
3/8" ~ 7/16"
16 - 18
5/8" ~ 11/16"
26 - 28
1" ~ 1 -1/8"




HOLLOW CAVITY ANCHOR



A111
SIZE
5 x 31
6 x 38




PVC EXTRUDED PLASTIC PLUG

A112
Color
Ø
YELLOW
M4
WHITE
M5
RED
M6
GREEN
M7
BLUE
M8
ORANGE
M10
GRAY
M13




PLASTIC RIBBED ANCHORS

A113
SIZE
SCREW
3/16 " x 7/8 "
3-4
1/4 " x 1"
5-6
5/16 " x 1-1/4 "
7-8



PLASTIC SCREW ANCHORS

A114
Outside Dia and Length
Use Screw Size
5 x 25
3-4
6 x 30
4-5
7 x 27
5-6
8 x 32
6-7
10 x 40
8-9



SUPPER ANCHORS

A115
SIZE
3/16" x 1"
1/4 " x 1-1/4"
5/16" x 1-1/2"



PE ANCHOR

A116
SIZE
5.8 x 21
1/4 x 1
1/4 x 1-1/4
1/4 x 1-3/8




NAIL & PLUG ASSEMBLY

A117
SIZE
10 x 80
10 x 100
10 x 120
10 x 140
10 x 160




TOGGLE ANCHOR

A118
SIZE
10 x 12






NYLON FRAME ANCHOR

A119
SIZE
8 x 100
8 x 140
10 x 75
10 x 100
10 x 120
10 x 140
10 x 165






E-Z ANCHOR

A120
SIZE
NYLON
3/8" x 32






SPEED ANCHOR NYLON

A121
SIZE
14.5 x 32MM




CYLINDER HEAD NAIL & PLUG ASSEMBLY TOGETHER

A123
SIZE
5 x 25
5 x 30
5 x 35
5 x 50
6 x 35
6 x 40
6 x 50
6 x 60
6 x 70
6 x 80
8 x 50
8 x 60
8 x 80
8 x 100
8 x 120
8 x 135
8 x 140
8 x 160
8 x 180
8 x 200
8 x 220
8 x 250




PLASTIC ANCHOR

A124
SIZE
10 x 50
12 x 60




PLASTIC ANCHOR

A125
SIZE
8 x 40




PLASTIC ANCHOR

A126
SIZE
10 x 60




PLASTIC ANCHOR

A127
SIZE
9.6 x 18.5




PLASTIC ANCHOR

A128
E-Z
SIZE
nylon
14 x 31




PLASTIC ANCHOR

A144
SIZE
6 x 35
8 x 50
10 x 60




E-Z ANCHORS & SCREW


A201
LTEM
SIZE
E-Z anchors
12 x 38
screw
4.2 x 30MM




E-Z ANCHORS & SCREW

A202
LTEM
SIZE
zinc alloy
12 x 42
nylon
12 x 42
screw
4.2 x 32






ZINC HAMMER DRIVE ANCHORS

A203
SIZE
HOLE SIZE
3/16 " x 7/8 "
3/16 "
1/4 " x 3/4"
1/4 "
1/4 " x 1 "
1/4 "
1/4 " x 1-1/4 "
1/4 "
1/4 " x 1-1/2"
1/4 "
1/4 " x 2"
1/4 "




SPEED ANCHOR

A204
SIZE
SCREW
M15 x 28.5
#8 x 30MM




METAL FRAME ANCHOR

A301
SIZE
M8 x 72
M8 x 92
M8 x 112
M8 x 132
M8 x 152
M8 x 182
M10 x 72
M10 x 92
M10 x 112
M10 x 132
M10 x 152
M10 x 182
M10 x 202




HOLLOW WALL ANCHOR J TYPE

A302
SIZE
4 x 25 5 x 45 6 x 58
4 x 39 5 x 58 6 x 71
4 x 45 5 x 71 6 x 88
4 x 52 5 x 88
4 x 60




H.C BOLT WITHOUT SCREW

A303
SIZE
6 x 50 8 x 60 10 x 65 12 x 80
6 x 55 8 x 65 10 x 75 12 x 90
6 x 65 8 x 75 10 x 85 12 x 100
6 x 75 8 x 85 10 x 110 12 x 115
6 x 85 8 x 90 10 x 135 12 x 135




TOGGLE BOLT WITHOUT WASHER

A304
SIZE
4 x 50
5 x 50
6 x 50
6 x 60
8 x 50
8 x 60




STEEL HAMMER ANCHOR

A305
SIZE
6 x 35
6 x 40
6 x 65
6 x 70






BLIND RIVET

A306
SIZE
3.2 x 6 4 x 6 4.8 x 6 6.4 x 10
3.2 x 8 4 x 8 4.8 x 8 6.4 x 12
3.2 x 10 4 x 10 4.8 x 10 6.4 x 16
3.2 x 12 4 x 12 4.8 x 12 6.4 x 18
3.2 x 16 4 x 14 4.8 x 14 6.4 x 20
  4 x 16 4.8 x 16 6.4 x 24
  4 x 18 4.8 x 18 6.4 x 28
    4.8 x 21
    4.8 x 24




EXPRESS NAIL

A307
SIZE
6 x 30 8 x 70
6 x 40 8 x 90
6 x 50 8 x 110
6 x 60 8 x 130
6 x 80 8 x 150
  8 x 180




DROP-IN ANCHOR

A308
SIZE
6 x 25 W1/4" x 25 W5/8" x 60
8 x 30 5/16" x 30 3/4" x 70
10 x 40 3/8" x 40
12 x 50 1/2" x 50
16 x 60




SLEEVE ANCHOR

A09
SIZE
5 x 37 10 x 60
6 x 40 10 x 80
6 x 60 10 x 100
8 x 50 12 x 70
8 x 60
8 x 80
8 x 100




BOLT BURST

A310
SIZE
6 x 50 1/4" x 50
6 x 65 1/4" x 65
8 x 65 5/16" x 65
8 x 70 5/16" x 70
8 x 80 5/16" x 80
10 x 75 3/8" x 75
10 x 100 3/8" x 100
10 x 120 3/8" x 120
12 x 100 1/2" x 100
12 x 120 1/2" x 120
16 x 125 5/8" x 125
16 x 150 5/8" x 150
16 x 175 5/8" x 175
20 x 200 3/4" x 200




SET ANCHOR

A311
SIZE
1/4" x 50
1/4" x 69
5/16" x 60
5/16" x 75
5/16" x 87
5/16" x 100
3/8" x 60
3/8" x 75
3/8" x 100
1/2" x 75
1/2" x 87
1/2" x 100
5/8" x 100
5/8" x 125
3/4" x 125
3/4" x 150
7/8" x 175




WEDGE ANCHOR

A313
SIZE
6 x 40 6 x 55 6 x 95
8 x 65 8 x 80 8 x 95
8 x 105 8 x 120 8 x 165
10 x 65 10 x 80 10 x 95
10 x 115 10 x 120 10 x 130
12 x 80 12 x 100 12 x 135
12 x 150 16 x 105 16 x 140
16 x 180 16 x 220




Sleeve anchor with bolt & red plastic

A314




Sleeve anchor with bolt & red plastic

A315




Sleeve anchor with bolt & red plastic

A316




Sleeve anchor with bolt & red plastic

A317




Sleeve anchor with bolt & red plastic



A318




Sleeve anchor with bolt & red plastic

A319
